Bakerloo - Black PIR Wall Lamp with Clear Glass

The Bakerloo has a clean outdoor lantern form with a rectangular wall plate, projecting upper arm and cylindrical clear shade. Current Searchlight information identifies the fitting as black metal with a clear polycarbonate shade, while the open, transparent design keeps the chosen E27 bulb visible. This makes the appearance of the bulb an important part of the finished look. The polycarbonate shade is also described by Searchlight as vandal-proof, providing a practical alternative to more fragile diffuser materials in suitable exterior locations.

This wall light uses one replaceable E27 bulb, which is not included. LED bulbs are suitable, so the colour temperature and brightness can be selected to suit the application. The clear shade allows light to spread around the exposed lamp rather than restricting it to a narrow beam.

An integrated PIR motion sensor provides automatic switching. According to Searchlight's installation instructions, the sensor has an optimum detection angle of 90 degrees and an adjustable detection distance from 200 cm to 800 cm. The illumination time can be adjusted from approximately 10 seconds to 4 minutes, while the lux control can be set from daylight operation through to activation in darker conditions. For best sensor performance, Searchlight recommends installing the fitting vertically on a solid surface at a height of 180 cm.

The current Searchlight product specification identifies this fitting as non-dimmable.

• Covered entrance and doorway lighting
• Sheltered porches and exterior wall areas
• Patios close to the house
• Side and back doors where automatic light is useful
• Exterior access routes within the PIR detection area
• Modern and modern classic exterior schemes
• Locations where a visible decorative E27 bulb suits the design

• Integrated PIR sensor switches the light on automatically when movement is detected.
• Adjustable sensor range from 200 cm to 800 cm helps tailor detection to the installation area.
• Adjustable illumination time allows the lamp to remain on for approximately 10 seconds to 4 minutes.
• Lux adjustment lets the activation threshold be set for different ambient light levels.
• Clear polycarbonate shade leaves the bulb visible and distributes light around the fitting.
• Replaceable E27 lampholder provides a choice of compatible LED bulbs.
• IP44 protection makes the fitting suitable for appropriate sheltered outdoor installations.
• Vandal-proof polycarbonate shade provides a practical diffuser material for exterior use.
• Compact 29 cm high by 12 cm wide format suits many domestic exterior walls.

• Combines exterior wall lighting and motion detection in one fitting.
• Adjustable PIR range, operating time and lux level provide useful installation flexibility.
• Replaceable E27 lamp means the light source can be changed without replacing the complete fitting.
• Clear shade makes it suitable where the chosen bulb is intended to remain visible.
• IP44 construction is designed for suitable outdoor positions, with installation under cover recommended by Searchlight.

Does the Searchlight Bakerloo 8631BK include a bulb?

No. It requires one E27 bulb, which must be purchased separately. The replaceable lampholder is compatible with LED bulbs, so you can choose a suitable light output and colour temperature for the location.

How far can the PIR sensor detect movement?

The PIR detection distance can be adjusted from 200 cm up to a maximum of 800 cm, with an optimum detection angle of 90 degrees. Searchlight recommends mounting the fitting 180 cm above the ground for best results.

Can the PIR operating time be adjusted?

Yes. The period that the lamp remains illuminated can be adjusted from approximately 10 seconds to 4 minutes. A separate lux control also allows the sensor activation level to be adjusted according to ambient light conditions.

Can the Bakerloo 8631BK be used outdoors?

Yes. It has an IP44 rating and is intended for outdoor installation. Searchlight specifically recommends fitting it under cover, making sheltered entrances, porches and similar protected exterior wall positions appropriate locations.

Is the Searchlight 8631BK dimmable?

No. The current Searchlight product specification identifies the Bakerloo 8631BK as non-dimmable. Its main control feature is the integrated PIR motion sensor with adjustable time, range and lux settings.
